| 2D43-570CPV | .67 ~ 0.91 inches (17 ~ 23 mm) | 5.28 inches (134 mm) | 9.21 inches (234 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 2-Spindle | QUOTE |
| 2D43-570CP | 0.68 ~ 0.91 inches (17.2 ~ 23 mm) | 5.28 inches (134 mm) | 9.37 inches (238 mm) | 3.58 inches (91 mm) | N/A | 2-Spindle | QUOTE |
| 2D43-5100CPV | 0.91 ~ 3.58 inches (23 ~ 91 mm) | 5.28 inches (134 mm) | 9.60 inches (244 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 2-Spindle | QUOTE |
| 2D43-5100CPVB | 0.91 ~ 3.58 inches (23 ~ 91 mm) | 5.28 inches (134 mm) | 9.60 inches (244 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 2-Spindle | QUOTE |
| 2D53-5100CP | 0.96 ~ 1.61 inches (24.2 ~ 41 mm) | 7.56 inches (192 mm) | 12.44 inches (316 mm) | 4.57 inches (116 mm) | N/A | 2-Spindle | QUOTE |
| 2D53-10130CPV | 1.61 ~ 4.92 inches (41 ~ 125 mm) | 7.56 inches (192 mm) | 12.44 inches (316 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 2-Spindle | QUOTE |
| 2D63-5100CP | 0.96 ~ 1.61 inches (24.2 ~ 41 mm) | 7.56 inches (192 mm) | 12.87 inches (327 mm) | 4.57 inches (116 mm) | N/A | 2-Spindle | QUOTE |
| 2D63-10130CPV | 1.61 ~ 4.92 inches (41 ~ 125 mm) | 7.56 inches (192 mm) | 12.87 inches (327 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 2-Spindle | QUOTE |
| 3D43-550CP | 0.50 ~ 0.67 inches (12.6 ~ 17 mm) | 5.28 inches (134 mm) | 9.01 inches (229 mm) | 3.58 inches (91 mm) | N/A | 3-Spindle | QUOTE |
| 3D43-570CPV | 0.67 ~ 0.91 inches (17 ~ 23 mm) | 5.28 inches (134 mm) | 9.21 inches (234 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 3-Spindle | QUOTE |
| 3D43-570CPVB | 0.67 ~ 0.91 inches (17 ~ 23 mm) | 5.28 inches (134 mm) | 9.21 inches (234 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 3-Spindle | QUOTE |
| 3D43-570CP | 0.68 ~ 0.91 inches (17.2 ~ 23 mm) | 5.28 inches (134 mm) | 9.37 inches (238 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 3-Spindle | QUOTE |
| 3D43-570CPB | 0.68 ~ 0.91 inches (17.2 ~ 23 mm) | 5.28 inches (134 mm) | 9.37 inches (238 mm) | 3.58 inches (91 mm) | N/A | 3-Spindle | QUOTE |
| 3D43-5100CPV | 0.91 ~ 3.07 inches (23 ~ 78 mm) | 5.28 inches (134 mm) | 9.60 inches (244 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 3-Spindle | QUOTE |
| 3D43-5100CPVB | 0.91 ~ 3.07 inches (23 ~ 78 mm) | 5.28 inches (134 mm) | 9.60 inches (244 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 3-Spindle | QUOTE |
| 3D53-5100CP | 0.96 ~ 1.61 inches (24.2 ~ 41 mm) | 7.56 inches (192 mm) | 12.44 inches (316 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 3-Spindle | QUOTE |
| 3D53-10130CPV | 1.61 ~ 4.25 inches (41 ~ 108 mm) | 7.56 inches (192 mm) | 12.44 inches (316 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 3-Spindle | QUOTE |
| 3D63-5100CP | 0.96 ~ 1.61 inches (24.2 ~ 41 mm) | 7.56 inches (192 mm) | 12.87 inches (327 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 3-Spindle | QUOTE |
| 3D63-10130CPV | 1.61 ~ 4.25 inches (41 ~ 108 mm) | 7.56 inches (192 mm) | 12.87 inches (327 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 3-Spindle | QUOTE |
| 4D43-550CP | 0.50 ~ 0.67 inches (12.6 ~ 17 mm) | 5.28 inches (134 mm) | 9.01 inches (229 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 4-Spindle | QUOTE |
| 4D43-570CPV | 0.67 ~ 0.91 inches (17 ~ 23 mm) | 5.28 inches (134 mm) | 9.21 inches (234 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 4-Spindle | QUOTE |
| 4D43-570CPVB | 0.67 ~ 0.91 inches (17 ~ 23 mm) | 5.28 inches (134 mm) | 9.21 inches (234 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 4-Spindle | QUOTE |
| 4D43-570CP | 0.68 ~ 0.91 inches (17.2 ~ 23 mm) | 5.28 inches (134 mm) | 9.37 inches (238 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 4-Spindle | QUOTE |
| 4D43-570CPB | 0.68 ~ 0.91 inches (17.2 ~ 23 mm) | 5.28 inches (134 mm) | 9.37 inches (238 mm) | 3.58 inches (91 mm) | N/A | 4-Spindle | QUOTE |
| 4D43-5100CPV | 0.91 ~ 2.52 inches (23 ~ 64 mm) | 5.28 inches (134 mm) | 9.60 inches (244 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 4-Spindle | QUOTE |
| 4D43-5100CPVB | 0.91 ~ 2.52 inches (23 ~ 64 mm) | 5.28 inches (134 mm) | 9.60 inches (244 mm) | 6.85 inches (174 mm) | 3.58 inches (91 mm) | 4-Spindle | QUOTE |
| 4D53-5100CP | 0.96 ~ 1.61 inches (24.2 ~ 41 mm) | 7.56 inches (192 mm) | 12.44 inches (316 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 4-Spindle | QUOTE |
| 4D53-10130CPV | 1.61 ~ 3.46 inches (41 ~ 88 mm) | 7.56 inches (192 mm) | 12.44 inches (316 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 4-Spindle | QUOTE |
| 4D63-5100CP | 0.96 ~ 1.61 inches (24.2 ~ 41 mm) | 7.56 inches (192 mm) | 12.87 inches (327 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 4-Spindle | QUOTE |
| 4D63-10130CPV | 1.61 ~ 3.46 inches (41 ~ 88 mm) | 7.56 inches (192 mm) | 12.87 inches (327 mm) | 10.00 inches (254 mm) | 4.57 inches (116 mm) | 4-Spindle | QUOTE |
