Model #Spindle Center Distance (min to max)Erickson Collet SeriesChucking Capacity (inches/mm)Type of Tap Holding DSpindle MotorList Price
2TC-E1040TBFUE0.40 ~ 0.48 inches (10 ~ 12 mm)N/ANumber 0 to Number 8 (M1.6 to M4)Centering3.46 inches (88 mm)3-SpindleQUOTE
2TC-E1050TBFUE0.48 ~ 0.56 inches (12 ~ 14 mm)N/ANumber 0 to Number 10 (M1.6 to M5)Centering3.46 inches (88 mm)3-SpindleQUOTE
2TC-E1080TBFUE0.56 ~ 0.60 inches (14 ~ 15 mm)N/ANumber 0 to Number 12 (M1.6 to M5)Centering 3.46 inches (88 mm)3-SpindleQUOTE
2TC-E1040BFU0.60 ~ 2.36 inches (15 ~ 60 mm)300Number 0 to Number 8 (M1.6 to M4)Centering3.46 inches (88 mm)3-SpindleQUOTE
2TC-E3080BFU0.91 ~ 3.58 inches (23 ~ 91 mm)JTCNumber 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)4.88 inches (124 mm)3-SpindleQUOTE
2TD-3080BFU-10.91 ~ 1.14 inches (23 ~ 29 mm)JTC Number 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)5.43 inches (138 mm)3-SpindleQUOTE
2TD-3080BFU-21.14 ~ 3.54 inches (29 ~ 90 mm)JTCNumber 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)5.43 inches (138 mm)3-SpindleQUOTE
2TD-3080BFU-33.54 ~ 5.11 inches (90 ~ 130 mm)JTCNumber 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)7.01 inches (178 mm)3-SpindleQUOTE
2TD-60120BFU-11.38 ~ 3.54 inches (35 ~ 90 mm)KTC1/4 to 1/2 (M6 to M12)Floating Number 0.016 (0.4)5.43 inches (138 mm)3-SpindleQUOTE
2TD-60120BFU-23.54 ~ 4.84 inches (90 ~ 123 mm)KTC1/4 to 1/2 (M6 to M12)Floating Number 0.016 (0.4)7.01 inches (178 mm)3-SpindleQUOTE
2TD-80160BFU-11.78 ~ 3.46 inches (45 ~ 88 mm)KTC5/16 to 5/8 (M8 to M16)Floating Number 0.016 (0.4)5.43 inches (138 mm)3-SpindleQUOTE
2TD-80160BFU-23.46 ~ 4.76 inches (88 ~ 121 mm)KTC5/16 to 5/8 (M8 to M16) Floating Number 0.016 (0.4)7.01 inches (178 mm)3-SpindleQUOTE
3TC-E1040TBFUE0.40 ~ 0.48 inches (10 ~ 12 mm)N/ANumber 0 to Number 8 (M1.6 to M4)Centering 3.46 inches (88 mm)3-SpindleQUOTE
3TC-E1050TBFUE0.48 ~ 0.56 inches (12 ~ 14 mm)N/ANumber 0 to Number 10 (M1.6 to M5)Centering3.46 inches (88 mm)3-SpindleQUOTE
3TC-E1080TBFUE0.56 ~ 0.60 inches (14 ~ 15 mm)N/A Number 0 to Number 12 (M1.6 to M5)Centering 3.46 inches (88 mm)3-SpindleQUOTE
3TC-E1040BFU0.60 ~ 2.04 inches (15 ~ 52 mm)300Number 0 to Number 8 (M1.6 to M4)Centering 3.46 inches (88 mm)3-SpindleQUOTE
3TC-E3080BFU0.91 ~ 3.07 inches (23 ~ 78 mm)JTC Number 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)4.88 inches (124 mm)3-SpindleQUOTE
3TD-3080BFU-11.14 ~ 3.14 inches (29 ~ 80 mm)JTCNumber 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)5.43 inches (138 mm)3-SpindleQUOTE
3TD-3080BFU-23.14 ~ 4.33 inches (80 ~ 110 mm)JTCNumber 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)7.01 inches (178 mm)3-SpindleQUOTE
3TD-60120BFU-11.38 ~ 3.07 inches (35 ~ 78 mm)KTC1/4 to 1/2 (M6 to M12)Floating Number 0.016 (0.4)5.43 inches (138 mm)3-SpindleQUOTE
3TD-60120BFU-23.07 ~ 4.17 inches (78 ~ 106 mm)KTC1/4 to 1/2 (M6 to M12) Floating Number 0.016 (0.4)7.01 inches (178 mm)3-SpindleQUOTE
4TC-E1050TBFUE0.48 ~ 0.56 inches (12 ~ 14 mm)N/ANumber 0 to Number 10 (M1.6 to M5)Centering3.46 inches (88 mm)4-SpindleQUOTE
4TC-E1080TBFUE0.56 ~ 0.60 inches (14 ~ 15 mm)N/ANumber 0 to Number 12 (M1.6 to M5)Centering3.46 inches (88 mm)4-SpindleQUOTE
4TC-E1040BFU0.60 ~ 2.51 inches (15 ~ 64 mm)300Number 0 to Number 8 (M1.6 to M4)Centering4.88 inches (124 mm)4-SpindleQUOTE
4TC-E3080BFU0.91 ~ 2.51 inches (23 ~ 64 mm)JTCNumber 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)4.88 inches (124 mm)4-SpindleQUOTE
4TD-3080BFU-11.14 ~ 2.60 inches (29 ~ 66 mm)JTCNumber 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)5.43 inches (138 mm)4-SpindleQUOTE
4TD-3080BFU-22.60 ~ 3.66 inches (66 ~ 93 mm)JTCNumber 3 to 5/16 (M3 to M8)Floating Number 0.008 (0.2)7.01 inches (178 mm)4-Spindle QUOTE
4TD-60120BFU1.38 ~ 3.38 inches (35 ~ 86 mm)KTC 1/4 to 1/2 (M6 to M12)Floating Number 0.016 (0.4)7.01 inches (178 mm)4-SpindleQUOTE
